PA-SOD-2006-D310-16/2 SOIC Prototyping Adapter (16-Pin, 0.208″ / 5.28 mm Body Width, 0.050″ / 1.27 mm Pitch) with 50×50 mil Header and Two 16-Pin 0.310″ SO-Plugs

Overview

The PA-SOD-2006-D310-16/2 SOIC Prototyping Adapter delivers a reliable and reusable solution for engineers and developers working with 16-pin SOIC (0.208″ / 5.28 mm body width, 0.050″ / 1.27 mm pitch) devices.
It includes a precision SOIC test socket, a 50×50 mil (0.050″ grid) header interface, and two 16-pin 0.310″ SO-Plugs for flexible test and integration setups.
Compliant with JEDEC MS-158, this adapter is ideal for circuit validation, device characterization, and R&D prototyping where repeatable socketing and clean signal paths are essential.

Technical Specifications

Key Features

• Supports SOIC-16 (0.208″ / 5.28 mm) packages per JEDEC MS-158.

• Includes two 16-pin 0.310″ SO-Plugs for modular connection and test setup.

• Provides 1 : 1 pin mapping for accurate signal evaluation.

• Connects directly to a 50×50 mil header for bench integration.

• Reusable design for lab or production test applications.

Applications

• Validation of SOIC-16 analog and logic ICs.

• MCU and sensor interface prototyping.

• R&D circuit debugging and signal analysis.

• Educational environments for device training and test.

Package Includes

• 1 × SOIC socket board (16-pin, 0.208″ / 5.28 mm body, 0.050″ / 1.27 mm pitch).

• 2 × SO-Plug modules (16-pin, 0.310″ spacing).

Compatibility

The PA-SOD-2006-D310-16/2 SOIC Prototyping Adapter supports SOIC-16 MS-158 devices including operational amplifiers, comparators, and digital interface ICs.

Fit & Footprint Notes

Ensure the target device matches JEDEC MS-158 dimensions (0.208″ body width, 0.050″ lead pitch) for proper fit and alignment.

Why Choose This Adapter

• Reusable platform for SOIC-16 testing and evaluation.

• Compliant with JEDEC MS-158 mid-body standard.

• Precision machining for signal stability and mechanical durability.

Add to Your Test Bench

Simplify your SOIC-16 device validation with the PA-SOD-2006-D310-16/2 SOIC Prototyping Adapter, featuring JEDEC MS-158 compatibility and dual SO-Plugs for modular prototyping.
