PA32Q-1498-1

Overview

PA32Q-1498-1 is a QFP to DIP programming adapter designed to support 32-pin QFP devices in a 32-pin DIP footprint.

The top interface is a 32-pin QFP socket. The bottom interface is a 32-pin DIP plug with 0.600″ row spacing.

The adapter is wired 1:1, maintaining direct pin mapping between the QFP device and the DIP interface.

Technical Specifications

• Top Interface: 32-Pin QFP Socket
• Bottom Interface: 32-Pin DIP Plug
• DIP Row Spacing: 0.600″
• Routing: 1:1 Pin Mapping
• Application: Device Programming

Compatibility

Designed for programming systems requiring a 32-pin DIP footprint while supporting compatible 32-pin QFP devices.
