QFP-128 to DIP-28 Programming Adapter — Clamshell Socket

Overview

PA1048-T128-01A is a device-specific programming adapter designed for 128-pin QFP packages with a 0.40 mm pitch. It converts a QFP interface into a 28-pin DIP footprint using a non-1:1 signal mapping configuration.

Interface

• Top interface: 128-pin QFP, 0.40 mm pitch
• Bottom interface: 28-pin DIP
• Device body size: 20 × 20 mm
• Tip-to-tip size: 22 × 22 mm

Key Features

• Socket type: Clamshell
• Wiring type: Device-specific mapping (non-1:1)
• Clamshell mechanism supports secure device placement and repeatable handling

Compatibility

• Lattice 1048C
• Lattice 2096

Technical Specifications

• Pitch: 0.40 mm
• Device body size: 20 × 20 mm
• Tip-to-tip size: 22 × 22 mm
• Top interface pin count: 128
• Bottom interface pin count: 28
• Socket type: Clamshell
• Wiring type: Device-specific mapping (non-1:1)
• Supported devices: Lattice 1048C, 2096
