QFP-48 to DIP-48 Programming Adapter — Clamshell Socket

Overview

PA48QD-806 is a device-specific programming adapter designed for 48-pin QFP packages with a 0.50 mm pitch. It converts a QFP interface into a 48-pin DIP footprint with a 0.6″ span using a rotational signal mapping configuration.

Interface

• Top interface: 48-pin QFP, 0.50 mm pitch
• Bottom interface: 48-pin DIP, 0.6″ span
• Device body size: 7 × 7 mm
• Tip-to-tip size: 9 × 9 mm

Key Features

• Socket type: Clamshell
• Wiring type: Rotational mapping (non-1:1)
• Clamshell mechanism supports secure device placement and repeatable handling

Compatibility

• Generic 48-pin QFP devices (pinout dependent)

Technical Specifications

• Pitch: 0.50 mm
• Device body size: 7 × 7 mm
• Tip-to-tip size: 9 × 9 mm
• Top interface pin count: 48
• Bottom interface pin count: 48
• DIP span: 0.6″
• Socket type: Clamshell
• Wiring type: Rotational mapping (non-1:1)
• Supported devices: Generic 48-pin QFP devices (pinout dependent)
