QFP-64 to DIP-40 Programming Adapter — Microchip PIC17C752 — Clamshell Socket

Overview

PA756-64Q is a device-specific programming adapter designed for Microchip PIC17C752, PIC17C756, and PIC16C923 devices, converting a QFP-64 package into a DIP-40 footprint to enable reliable programming and testing.

Interface

• Top interface: QFP-64, 0.50 mm pitch
• Bottom interface: DIP-40, 0.6″ span
• Device body size: 12 × 12 mm
• Tip-to-tip dimensions: 14 × 14 mm

Key Features

• Clamshell socket for secure device insertion and removal
• Device-specific mapping (non-1:1) for correct signal routing
• Designed for repeatable programming and handling reliability

Compatibility

Microchip PIC17C752, PIC17C756, PIC16C923

Technical Specifications

• Pitch: 0.50 mm
• Device body size (X × Y): 12 × 12 mm
• Tip-to-tip size: 14 × 14 mm
• Top interface pin count: 64
• Bottom interface pin count: 40
• Socket type: Clamshell
• Wiring type: Device-specific mapping (non-1:1)
• Supported devices: Microchip PIC17C752, PIC17C756, PIC16C923
